Multi-Constraint Metadata Queries: Analysis And Solution

by Pedro Alvarez 57 views

Issue Summary

Problem: Multi-constraint listing queries (e.g., latest N items of specific file type, optionally about a target term) return incorrect results:

  • Returns default count instead of requested count.
  • Includes file types outside the requested type synonyms.
  • Does not apply content filtering when a target term is present.

Root Cause Analysis

Current behavior (simplified):

Query: "List N latest <type-synonym> that mention <target-term>"
-> Intent Classification: METADATA_QUERY (correct for listing)
-> Orchestrator Plan: Single step (return_metadata)
-> Discovery Agent: get_latest_files() (no parameters)
-> Metadata Plugin: Defaults (count=10, no file_type filter)
-> Result: Default-sized mixed file list without content filtering

Expected behavior (simplified):

Query: "List N latest <type-synonym> that mention <target-term>"
-> Intent Classification: METADATA_QUERY (listing intent)
-> Orchestrator Plan: Two steps (metadata narrowing, then content filtering when target-term exists)
   Step 1: Metadata filtering (count=N, file_type mapping from synonym, recency)
   Step 2: Content filtering (semantic search restricted to Step 1 result set)
-> Result: Exactly N items of the requested type, matching the target term, most recent first

Single Design: Constraint-aware orchestration with two-step narrowing

Implement a ConstraintExtractor + Orchestrator pattern that always respects explicit user constraints and adds a second semantic step only when a content term is present.

1) ConstraintExtractor (new utility)

Purpose: Convert natural-language constraints into a typed structure the orchestrator and plugins can use.

Contract:

  • Input: query: str
  • Output (dataclass QueryConstraints):
    • count: Optional[int] — requested number of items if present, else None (defaults applied later).
    • file_types: list[str] — canonical extensions, e.g., ["PPTX","PPT"] for “decks”, ["PDF"] for “pdfs”, ["DOCX","DOC"], ["XLSX","XLS"].
    • recency: bool — true if words like “latest”, “newest”, “recent” are present.
    • content_terms: list[str] — remaining meaningful terms after removing constraint tokens and stopwords.
    • sort_by: Literal["modified_time"] (default).
    • sort_order: Literal["desc"] (default).

Behavior:

  • Extract numbers from digits and number words (one..twenty); bound to a safe range (e.g., 1–100).
  • Map type synonyms deterministically (decks→PPTX/PPT, spreadsheets→XLSX/XLS, docs→DOCX/DOC, pdfs→PDF).
  • Normalize to uppercase extensions used by the metadata schema.
  • Remove constraint keywords and standard stopwords to form content_terms (stable order).

Placement:

  • File: backend/shared/constraints.py (new) or backend/shared/utils.py if preferred.

2) Orchestrator: constraint-aware plan construction

Plan logic for METADATA_QUERY:

  • Call ConstraintExtractor.extract(query).
  • If content_terms is empty:
    • Single metadata step: call get_latest_files with parameters:
      • count: constraints.count or default_latest_count (from config).
      • file_type: if constraints.file_types has one value, pass it; if multiple, pass list (see plugin note below).
    • Sorting: by modified time desc, with stable tie-breaker.
  • If content_terms is non-empty:
    • Two-step plan:
      1. Metadata step: call get_latest_files with file_type (if any) and widened count to ensure sufficient pool for content filtering. Widen factor (e.g., 3) is configurable and bounded.
      2. Content step: semantic search limited to the metadata result set (target_docs), using content_terms joined as a query. Clip to requested count with stable tie-breaking.

Notes:

  • Keep overall intent as METADATA_QUERY for such listing queries; the presence of a target content term only affects the plan shape.
  • Deterministic ordering is required at each step.

3) Metadata plugin usage and determinism

Metadata step parameters:

  • operation: get_latest_files.
  • count: integer (requested or widened when content step follows).
  • file_type: uppercase extension string or list of strings.

Sorting:

  • Ensure SQL uses ORDER BY modified_time DESC, file_name ASC (stable tie-breaker).

Multiple file types:

  • If enhanced schema supports IN (...), use it; otherwise fetch and filter client-side deterministically.

4) Semantic filtering restricted to metadata results

Search parameters (for semantic plugin):

  • question: join of content_terms or the original residual content phrase.
  • target_docs: list of file paths from the metadata step (restricts search domain).
  • k: min(configured max, len(target_docs)).
  • max_documents: requested count.

Sorting and clipping:

  • Sort by similarity desc, then by path asc (stable tie-breaker), and return exactly the requested count when available.

5) Configuration and logging

Configuration (via shared.config.Config and template):

  • default_latest_count: default N when none provided (e.g., 10).
  • content_filter_widen_factor: widening multiplier for Step 1 when Step 2 exists (e.g., 3; clip to reasonable max such as 50).
  • semantic_max_k: upper bound for k in semantic step (e.g., 50).

Logging (structured, debug level):

  • Extracted constraints.
  • Step parameters (sanitized) and sizes in/out.
  • Final count and applied ordering.

Actionable Implementation Plan

  1. Add constraint extraction utility
  • File: backend/shared/constraints.py (new).
  • Implement @dataclass QueryConstraints and ConstraintExtractor.extract(query: str) -> QueryConstraints.
  • Include: number word map, type synonym map, stopwords, normalization, safe bounds.
  • Unit tests: tests/test_constraints.py covering numbers, types, recency detection, content terms.
  1. Wire constraints into orchestrator
  • File: backend/src/querying/agents/agentic/orchestrator_agent.py.
  • In the METADATA_QUERY path, call ConstraintExtractor.extract(query).
  • Build either a single-step metadata plan (no content_terms) or a two-step plan (with content_terms).
  • Pass count and file_type into the metadata step; pass target_docs and max_documents into the semantic step.
  1. Ensure discovery agent forwards parameters
  • File: backend/src/querying/agents/agentic/discovery_agent.py.
  • When executing metadata commands for latest files, include count and file_type from the plan step parameters.
  1. Stabilize metadata plugin ordering and multi-type support
  • File: backend/src/querying/agents/plugins/metadata_commands.py.
  • Ensure ORDER BY modified_time DESC, file_name ASC.
  • If multiple file_type values are provided:
    • Enhanced schema: use an IN clause with uppercase types.
    • Legacy schema: perform deterministic client-side filtering with stable ordering.
  1. Restrict semantic search to target docs and clip deterministically
  • File: semantic search caller (e.g., backend/src/querying/agents/agentic/analysis_agent.py).
  • Accept target_docs, set k conservatively, clip to requested count using stable tie-breaking (similarity desc, path asc).
  1. Deterministic, offline tests
  • Unit tests for ConstraintExtractor.
  • Orchestrator plan tests for:
    • Only metadata constraints (count, type, recency) -> single-step plan, exact count, correct ordering, correct type filtering.
    • Metadata + content constraints -> two-step plan with widened metadata pool and restricted semantic filtering, exact final count.
  • Integration test with a small deterministic dataset (mix of extensions and known timestamps). Mock semantic ranking to avoid network/embedding variability.

Success Criteria

  • Count constraint respected: returns exactly the requested number when available.
  • File type constraint respected: only requested type(s) appear in results.
  • Content constraint respected when present: semantic filtering applied within metadata-filtered set.
  • Deterministic ordering: metadata by modified time desc, tie-broken by file name; semantic by similarity desc, tie-broken by path.
  • Backward compatible: simple listing queries behave as before with defaults.

Related Components

  • backend/shared/constraints.py — constraint extraction (new).
  • backend/src/querying/agents/agentic/orchestrator_agent.py — plan construction.
  • backend/src/querying/agents/agentic/discovery_agent.py — metadata execution with parameters.
  • backend/src/querying/agents/plugins/metadata_commands.py — latest files query parameters and ordering.
  • backend/src/querying/agents/agentic/analysis_agent.py — semantic filtering restricted to target docs.

Notes

This design keeps concerns separated and testable: parsing, planning, metadata filtering, and semantic filtering are modular. It respects project constraints (no network in tests, deterministic outputs, config-driven behavior) and avoids personal or environment-specific examples.
